ForceBand 是一种低成本腕戴式 sEMG+IMU 手环,通过 EMG2Force 模型(DINOv2 ViT‑S 频谱编码器 + Transformer)预测每根手指指尖的力。

Stars

52

7 天增长

暂无数据

Fork 数

3

开放 Issue

1

开源协议

Apache-2.0

最近更新

2026-07-24

AI 仓库情报摘要
FR-AI / ANALYSIS

为什么值得关注

它提供了开源、预训练的模型,能够从表面肌电图实现强大的指尖力预测,并通过简单的校准流程将机器人演示中的误差降低约 5 倍。

适合谁使用

  • 从事灵巧操作的机器人研究者
  • 开发可穿戴输入设备的人机交互工程师
  • 寻求非侵入力估计的假肢开发者
  • 研究肌电力量推断的学术人员

典型使用场景

  • 通过校准将人类手部力量技能迁移至机器人手
  • 估计假肢或外骨骼控制中的抓握力
  • 分析精细运动技能或康复进展
  • 使用低成本硬件实现力感知交互系统

项目优势

  • 在 Apache‑2.0 许可下发布了开源预训练检查点和验证数据
  • 在少量演示集上校准使力预测误差降低约 5 倍(MAE 从 46.0 降至 9.5)
  • 在保留的会话中拇指/食指/中指力跟踪良好(R² 0.68/0.65/0.50)
  • 低成本硬件设计,公开了物料清单和肌电硬件调查

使用前须知

  • 完整预训练数据集和 DIY 硬件教程尚未发布
  • 环指和小指的力噪声较大且携带的力较小
  • 迁移到新设置(不同传感器放置或环境)时需要校准

README 快速开始

ForceBand: Learning Forceful Manipulation with sEMG



Official EMG2Force model code for "ForceBand: Learning Forceful Manipulation with sEMG" (arXiv:2606.26093 · project page).

ForceBand is a low‑cost wrist‑worn sEMG + IMU band; its EMG2Force model predicts per‑finger fingertip forces (thumb, index, middle, ring, pinky) from the 8‑channel sEMG + IMU stream — a DINOv2 ViT‑S spectrogram encoder + Transformer (~28.5 M params) that conditions on the previous window's force for continuity.

EMG2Force on a held‑out validation session — predicted (color) vs. ground‑truth (grey) per‑finger force. -->

What ships

ArtifactStatusWhere
✅ Pretrained checkpoint (DINOv2, Apache‑2.0)releasedcheckpoints/
✅ Validation set — held‑out pretraining chunks, ~5‑min quick checkpoint testreleaseddata/val/ · data/splits/val.txt
✅ Deploy‑demo set — calibration + held‑out validationreleaseddata/demos/ · data/splits/{calib,demo_val}.txt
⏳ Full pretraining datasetunder preparation
➕ RGB overlay videos (optional, ~1.3 GB)Google Drivescripts/download_videos.py

Roadmap

Before paper acceptance

  • Hardware Bill of Materials (BOM)
  • Hardware DIY tutorial (build your own ForceBand)
  • EMG hardware survey — sEMG front‑ends / electrodes / acquisition boards compared
  • Full pretraining dataset
  • Robot policy training pipeline
  • DINOv3 backbone variant — its license needs further validation on our side before we redistribute, so for now we ship DINOv2; planned as an opt‑in download‑DINOv3‑yourself recipe (the two perform on par — see Backbones)

Install

conda env create -f environment.yml && conda activate emg2force
pip install -e .                          # or: pip install -r requirements.txt

GPU recommended. **No bac
